Description
- 2 Channel Class D Full Range Technology
- 2Ω Stereo load Capability
- Audiophile Grade Nickel Plated RCA connectors
- Variable 12db High-Pass or Low-pass crossover filters
- Bridgeable outputs @ 4Ω load
- Marine Grade Conformal Coated Double Sided PCB
- Compatible with any 4/2Ω Loudspeaker
Features
| Output Power @ 14.4 VDC, 2Ω | 2 x 250W |
| Output Power @ 14.4 VDC, 4Ω | 2 x 125W |
| Output Power @ 14.4 VDC, 4Ω Bridge | 1 x 500W |
| Power Supply Input Voltage | 12VDC to 14.8VDC |
| THD (1kHz @ 4Ω) | 0.04% |
| Bandwidth (-3dB) | 18Hz- 22KHz |
| Damping Factor (1k Hz @ 4Ω) | 100 |
| S/N ratio (as weighted @ 1 Volt) | 99dB |
| Input Sensitivity | 0.2MV - 6V |
